SS 316/316L Washer
Stainless Steel 316 / 316L Washer Manufacturer in Vadodara, India
UNS S31600 Washers Dealer, SS 316 Washer, Stainless Steel 316L Washers, SS 1.4436 Washer Fastener, SS 316L Washers, Stainless Steel 316 Washers, SS S31603 Washers Manufacture in Vadodara, India.
GreatBolt Industries is a well-known exporter, supplier, and manufacture of stainless steel 316/ 316L washer. It is available in various materials, finishes, and grades in metric and inch sizes. We are providing our products in various industrial applications such as mining, equipment manufacturing, industrial construction, transportation, aluminum manufacturing, oil refineries, food processing, etc.
The washer is a component that is used in combining with a fastener. It is mostly used to keep the screw from loosening, and it divides the pressure of fastener over a big surface. To avoid loosening many other kinds of washers are used.
Annealing grade 316 and 316L stainless steel needs heat temperature between 1900 and 2100 degrees Fahrenheit before quick quenching.
Grade 316 stainless steel contains extra carbon than 316L. As l stands for “low,” but it contains less carbon. It is a very strong, a better choice for high-stress situation, and corrosion resistance respectively.
Grade 316L is a good choice for projects that need lots of welding. Grade 316 is very liable to weld decay than grade 316L. It also is a good stainless steel for high corrosion uses, and high temperature that is the reason why it is more popular in marine and construction projects.
There are some benefits of stainless steel 316/ 316L washer that include greater tensile yield strength, increased carbon content heat resistant qualities, and greater short and long term creep strength.
Stainless Steel 316 Tab Washer, SS 316 Spring Washers, Stainless Steel 316L Tooth Washer, DIN 1.4436 / 1.4404 Taper Washers, Stainless Steel 316 Plain Washer, SUS 316 Star Washers Exporter in India.
Stainless Steel 316 Spring Washer, SS 316L Taper Washer, SS 316L Plain Washers, Stainless Steel 316L Washer Stockholder, Stainless Steel 316 Tab Washer Supplier.
The typical mechanical properties of stainless steel are proof stress, tensile strength, elongation, and hardness.
We ensure the quality of materials by strict quality tests. The tests are mechanical test, hardness test, chemical analysis, positive material identification, flattening test, micro & macro test, pitting resistance test, flaring test, and intergranular corrosion (IGC) test. We also provide the documentation of the products to our customers, such as heat treatment charts, quality assurance plans, material traceability records, fumigation certificates, material test certificates, guarantee letter, and many more.
Stainless Steel 316 / 316L Washers Types
Stainless Steel 316/
316L Plain Washer
Stainless Steel 316/
316L Spring Washer
Stainless Steel 316/
316L Tooth Washer
Stainless Steel 316/
316L Taper Washer
Stainless Steel 316/
316L Tab Washer
Stainless Steel 316/
316L Star Washer
Stainless Steel 316/
316L Flat Washer
Stainless Steel 316/
316L Dock Washer
Stainless Steel 316/
316L Split Washer
Stainless Steel 316/
316L Ogee Washer
Specification of SS 316/316L Washer
| Standard : | ASTM A /SA 193 / 194 |
| Dimension : | ASTM, DIN, BS, GB, IS and all International Standards |
| Length : | 3 mm to 200 mm |
| Washer Size : | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Heat Treatment: | Annealing, Stress Relieving, Case Hardening, Quenching and Tempering. |
| Type : | Plain Washer, Spring Washer, Tooth Washer, Tapper Washer, Tab Washer, Star Washer etc. |
Other Properties of SS 316 / 316L Washer
Equivalent Grades for SS 316 / 316L Washer
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17-11-02 / Z3CND18-14-03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
SS 310 Washer Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 | min. | – | – | – | – | 16.0 | 2.0-3.0 |
10.0 | – | |
| max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | – | ||
| 316L | min. | – | – | – | – | – | 16.0 | 2.0-3.0 | 10.0 | – |
| max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | – | - | |
Mechanical Properties of SS 316 / 316L Washer
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
People also search for DIN 1.4436 / 1.4404 Washer
Stainless steel 316 washers Distributors, 316 stainless steel washers dealer, ss 316 square dock washers supplier, ss 316 wave washer, ss 316 washers, ss 316l taper washers Suppliers in India, ss 316 tab washers, ss 316l washers, ss 316 sealing washer, ss 316l washers suppiler in india, a wide range of the stainless steel bs 316S31 washers price list, stainless steel 1.4401 belleville washer, ss 316l washers price, din 1.4436 flat washer, ss s31603 star washer with metric fine pitch, ss 1.4404 fender washer, ASTM A194 316 SS lock washer, ss 316 spring washer, ss 316l washers exporter, uns s31603 washers supplier in India, ss s31600 tooth washer, SS 316l washer manufacturer in maharashtra, ss 316 washers suppliers in mumbai, stainless steel din 1.4435 plain washer
Other Stainless Steel 316 / 316L Washer Types
USS flat washers, SAE flat washers, Structural washers F436, Fender washer, Lock washers, spring lock washer, High collar lock washer, Finishing washers, Dock washers, Square dock washer, Bonded sealing washers, Lock washers external tooth, Lock washers internal tooth, spherical washer, Belleville washers, Wave washers.
Quality Assurance of SS 316 / 316L Washers
Stainless Steel 316/316L Washers are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.
